Elevator door switch /HX-010 161 Elevator vide door switch elevator parts

Product Categories

Xi'an Excellent Electromechnical Co.,Ltd

Contact Now

Name: Elevator door switch HX010 161 Elevator vide door switch elevator parts
Brand: EST for elevator door switch
Price: 1 USD

Place of Origin : China for elevator door switch

Brand Name : EST for elevator door switch

Certification : ISO9001 for elevator parts

Model Number : HX-010 161 for elevator door switch

Type : elevator parts

use for : elevator door switch

MOQ : 50SETS

Price : USD1-25/SET

Packaging Details : 1 PC/Small box,50 PCS/ Carton

Delivery Time : 7-10 working days by DHL,EMS,Container ets

Payment Terms : TT, Paypal, Western Union

Supply Ability : 10000 piece /Month

Contact Now

Elevator door switch

P/N:HX-010/PO PIN Separate actuator

Product PC with transparent case and black base

Such contact type and electrical signal control switch

Comprehensively applied in elevator door control circuit

Silver contact style with high reliabitily

Foreign-made reed make life much higher,Compact structure make mounting must easier

Type	HX-010 161 Elevator vide door switch
Enclosure	PC/ transparent	Mechanical life	2*10 ^6
Actuatuator	Separate actuator 2*M4	Switching frequency	≤30min
Contact type	Closer/ 1 N.C.	Connection	2 PCS screws contact(M3/M5)
Conv. Thermal current	Ithe/4A	Protection type	IP20
Rated operational voltage	Ue/230 VAC;200V DC	Conductor cross-sections	0.5...1.5mm
Rated operational Current	Ie/2A	Approvals	CE&3C
Product choice	HX-010/A:161 Elevator vide door switch
Note:1 use for elevator door limit switch 2 Do not use this switch when the end of the baffle to avoid damage to the switch 3 Optional wired or wireless client line independent switch

Elevator door switch /HX-010 161 Elevator vide door switch elevator parts

Elevator door switch /HX-010 161 Elevator vide door switch elevator parts Images
